Product name：HB-3000B Brinell hardness tester (electronic reversing weight loading)
Product model：HB-3000B
Product range：1839、2452、7355、9807、29420牛頓
Immediate consultation
Online Message
HB-3000B Brinell hardness tester
The HB-3000B Brinell hardness meter adopts the electronic reversing switch, which has the characteristics of high testing precision, automatic test force loading, automatic time unloading and so on.
The hardness tester is used to determine Brinell hardness values of non quenched steel, cast iron, non-ferrous metal and soft bearing alloy. It is suitable for laboratories in metal metallurgical factories, machinery manufactory, industrial laboratories and professional schools.
The test power series......... 1839, 2452, 7355, 9807, 29420 Newton
The ball diameter............ 2.5, 5, 10 mm
The test force keeps time... 12, 30, 60 seconds
The maximum height of the sample...... 230 millimeter
The distance between the center of the head and the wall of the machine... 120 millimeter
The specifications of the motor...... 0.18 kW, 1410 rpm, 220 volt
The size of the hardness meter (long X width * high)... 700 X 268 x 842 mm
The net weight of the hardness meter... 220 kilograms of supply voltage... AC220V
