  • HRD-150 electric Rockwell hardness tester

Product name:HRD-150 electric Rockwell hardness tester

Product model:HRD-150

Product range:98.07N(10kgf)

Immediate consultationHRD-150 electric Rockwell hardness testerOnline Message

<
>

Product introduction

Hardness is an important index of mechanical properties of materials. It refers to the ability of a material to resist another object that does not take any residual deformation. Rockwell hardness test is one of the simplest, fastest and most economical test methods in mechanical performance test. Because it can directly indicate the hardness value, so the test efficiency is the highest. In many cases, other mechanical properties can not be completed. With the rapid development of scientific research and industry in China, Rockwell hardness test method has been widely used in national defense, scientific research, laboratory and factory workshop.

This hardness tester is applied to the laboratory of metal metallurgical factories, mechanical manufacturing plants, industrial laboratories and colleges and universities.


Standard of execution

GB/T230.2

Functional characteristics

Daping worktable 1

Xiaoping workbench 1

V type worktable 1

Diamond Head 120 degree 1

1.588 steel ball press head of steel ball 1

Diameter of 1.588 spare ball of diameter of 1.588, 5

Standard Rockwell hardness block 20-30HRC block 1

Standard Rockwell hardness block 35-55 HRC block 1

Standard Rockwell hardness block 60-70 HRC block 1

Standard Rockwell hardness block 80-88HRA block 1

Standard Rockwell hardness block 85-95HRB block 1


Technical parameter

1, the initial test force: 98.07N (10kgf)

2. Total test power: 588.4N (60kgf), 980.7N (100kgf), 1471N (150kgf).

3. Hardness resolution: 0.5HR

4, hold time (s):1~30

5. The maximum height of the test piece: 200mm

6, the distance between the indentation center and the wall of the machine: 135mm

7. The size of the hardness meter: 500 x 250 x 700mm

8. Working voltage: 220V/50HZ

9. The net weight of the hardness meter: 70kg
